Specifications
We offer a new generation of automatic lines for the production of bags and bags.
Detailed specification
These are technically advanced automatic machines that are designed for the automatic production of bags from PP, LDPE, HDPE, non-woven fabric, etc. The machines are designed as cost-effective units requiring a minimum of operator intervention during the production of bags/bags.
The machines are certified in accordance with European Union regulations on safety, health protection and environmental protection - EC safety certificate (CE).
Features of the automatic lines offered by us:
- processes films from PP, LDPE, HDPE, as well as non-woven fabric, etc.
- makes cross weld (by batting)
- makes bottom weld (weld-cut) Type of unwinding:
- folding wedge (triangle)
- double folding wedge (triangle)
- uniaxial unwinding on the machine
- biaxial unwinding on the machine Film braking method:
- electromagnetic brake
- mechanical brake Winding shafts: pneumatic expansion shaft • solid steel shaft with mandrels Edge leveling systems: • automatic • manual
Automatic line
The machines are certified in accordance with European Union regulations on safety, health protection and environmental protection - EC safety certificate (CE).
Semi-automatic line
The machines are certified in accordance with European Union regulations on safety, health protection and environmental protection - EC safety certificate (CE).
Technical parameters
Modules:
- monitoring the end of the film with an ultrasonic sensor
- knife for longitudinal division of the sleeve, side or center
- hot knife for longitudinal welding
- longitudinal perforation
- bottom tab
- inserting adhesive tape
- insertion of reinforcement
- ultrasonic welding
- waste extraction
- Euro slice
- ear slice
- rhubarb sections
- brand sensor
- 1. winding, driven by an async motor, speed controlled by compensator
- 2. , 3. traction driven by a servo motor
- upper launch rail on PE
- replaceable launch bar on PP
- exchangeable welding strip for the bottom weld
- module for transversal division of the foil when using the bottom weld
- belt conveyor
- belt conveyor - storage of bags
We use quality components from Siemens, Eaton, Festo, SMC, etc. (or we choose another brand that suits the customer best)
- Siemens electric motors
- Control system Siemens Simatic S7 1500
- Securing and switching technology Siemens, Eaton
- Pneumatic components Festo, Pneumax
