Specifications
- intended for rewinding, assembly and for quality control of labels
- rewinding according to the specified length or number of labels
- equipped with part of rotary die - for rotary die with die
Detailed specifications
The machine is intended for rewinding, assembly and quality control of labels made of materials such as paper, foil, laminates, etc.. With simultaneous longitudinal cutting, the machine is capable of rewinding according to the specified length or number of labels. The machine is equipped with a rotary die section - for rotary die cutting.
Technical parameters of the machine:
Width of rewound material max. 340 mm / processed max. 330 mm - or another dimension adapted to the needs of the client
Diameter of mother roll max 800mm
Diameter of the wound roll max 400mm
Waste roll diameter max 400mm
Working speed of the machine up to 220 m/min during standard work (Depending on the type of material)
Cutting method - with circular knives Unwinding sleeve diameter 76mm (3") - or other dimension adapted to the needs of the client
Winding sleeve diameter 76mm, 40mm, 25mm - or other size adapted to the needs of the client
